Waveshare IMX415 (IR-Cut) 8MP Camera Module
Waveshare IMX415 (IR-Cut) 8MP Camera Module
In stock
Regular price
$41.00 AUD
Regular price
Sale price
$41.00 AUD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
The IMX415-98 IR-CUT Camera is a high dynamic camera module suitable for Raspberry Pi mainboards and computer modules series as well as Luckfox Omni3576. Using Sony IMX462 starlight level sensor with 2 megapixels and built-in IR-CUT, it can freely switch between daytime full-color and night time camera modes through the onboard switch.
Specifications
| Sensor | IMX415 | CMOS size | 1/2.8″ |
| Camera type | Color | Recommended recording pixels |
Approx. 8.29MP (3840×2160) |
| Image size | Diagonal 6.43mm | Unit cell size | 1.45um (H) × 1.45um (V) |
| Aperture | F2.0 | Focal length | 3.95mm |
| FOV | 98° | Distortion | <1% |
| Applications | Suitable for AI applications such as facial recognition, road marking recognition, license plate recognition, etc. | ||
Wide field of view
Onboard 98° wide angle lens, provides a wider picture range and viewing angle
High SNR and Low Light Performance
Multiple Motherboards Support
Supports Raspberry Pi series boards
Compatible With Raspberry Pi 5 / Zero Series / Zero 2W Series Boards
Extra FPC Cable Is Required For Raspberry Pi 4B+ / 3B+ / 3B Series
Connecting with Raspberry Pi 5
Connecting with Raspberry Pi 4B
Connecting with Zero 2 W
Connecting with Zero W
Supports Luckfox series boards. Can be directly connected to Luckfox-Omni3576 Development Board
Connecting with Luckfox-Omni3576 Development Board
- For reference only, Raspberry Pi 4B, Raspberry Pi 5, Zero W, Zero 2 W, Luckfox-Omni3576, and yellow FPC are NOT included.
Outline dimensions
Package contents
Weight: 0.019 kg
- IMX415-98 IR-CUT Camera ×1
- 22-pin FPC cable ×1
Resources & Services
Wiki: www.waveshare.com/wiki/IMX415-98_IR-CUT_Camera
