Waveshare 10.1inch 800x1280 DSI Capacitive Touch Display

An excellent performance display with 178° wide viewing angle, suitable for use with most MIPI-DSI connections such as Raspberry Pi, Luckfox Omni, Luckfox Lyra, Luckfox Lyra Plus, and more!

Overview

• Size: 10.1" (Diagonal)
• Resolution: 800x1280
• Interface: DSI
• Panel Type: IPS
• Viewing Angle: 178°
• Touch Type: Capacitive
• Touch Points: 10
• Glass: Toughened
• Bonding: Optical
• Brightness: 500cd/m2

Device & System Support

• Raspberry Pi - Supports Raspberry Pi OS, 10-point touch
• RK3576 - Supports Buildroot / Debian / Ubuntu / Android, etc. 10-point touch
• RK3506 - Supports Buildroot / Ubuntu, etc. 10-point touch
• ESP32-P4 - Supports LVGL GUI programs, up to 10-point touch

Package Contents

• 1x 10.1-DSI-TOUCH-A ×1
• 1x MIPI-DSI-Cable-12cm x1
• 1x MX 1.25 2PIN to 2.54 3PIN cable x1
• 2x FFC 22PIN cable ~200mm (opposite sides)

The display orientation is portrait by default, with 800×1280 resolution (H×V). Change the software config for landscape display.
